概 述

整流變壓器是把電力網的三相交流電壓變換為所需要的，一定相繳的交流整流電壓、經整流元件整流后變 為所需要的直流電。 整流變壓器應用于化工、治金、電解、直流傳動、直流治煉、電廠勵磁等工業設備中。

訂貨須知

1、安裝條件：戶外安裝

2、海拔高度：1200mm

3、地震烈度；8度

4、氣象條件

4.1、環境溫度：-35℃~+40℃

4.2、日照強度：風速0.5/s時0.1W/cm

4.3、相對濕度：日平均不大于95%，月平均不大于90%（+25℃時）

4.4、結冰厚度：25mm

4.5、******風速：35m/s

summary

The rectifier transformer is used to convert the three-phase AC voltage of the power grid into the required AC rectifier voltage, which is converted into the required DC power after rectification by the rectifier element. Rectifier transformers are widely used in chemical industry, metallurgy, electrolysis, DC drive, DC smelting, power plant excitation and other industrial equipment.

Ordering instructions

1. Installation conditions: outdoor installation

2. Altitude: 1200mm

3. Seismic intensity; 8 degrees

4. Meteorological conditions

4.1. Ambient temperature: - 35 ℃~+40 ℃

4.2 Sunlight intensity: 0.1W/cm at wind speed of 0.5/s

4.3 Relative humidity: daily average is not more than 95%, monthly average is not more than 90% (at+25 ℃)

4.4 Ice thickness: 25mm

4.5. Maximum wind speed: 35m/s
